Lab Vacuum Sealing Machine For Preparing Pouch Cell


This is the video link for your reference.

https://www.youtube.com/watch?v=VuHwXQtTkOw&feature=youtu.be



Features

It mainly used for the first vacuum sealing of punch/polymer battery (soft-pack)lithium cell after injected and final sealing.

1)It can suitable for different specifications of battery,easily to adjust,only do the speed regulation(or change)clamp and adjust(or change)the related sealing head ok.

 2)There are battery pressing platen within the upper cabinet,to press the battery tightly and make the welding effrect better.

3)The sealing-head is made of copper materials, heat transfer effect is good save power consumption,improve work efficiency.

 4)The head temperature can set through the thermostat panel button control, the current value of the temperature and the set point can be through its LCD screen display, intuitive and easy operation.

Working principle

This equipment is used the tilt(flip type)to form a closed cavity,then pump the air in the cavity to form -90KP of in a negative pressure state,so that make the air within batteries core excluded.

Platen of the upper chamber use the cylinder pressing materials,and then trough sealing head using the heat conduction effect acting on a lithium battery packaging material(aluminium-laminated film),and heated close to the molten state softened and fused together.

Technical Parameter

Model

  Compact Vacuum Sealer   TMAX-YF

Source voltage

AC 220V/110V, 50/60HZ

Power

600W

Warranty

Two years limited warranty with lifetime support

Advantages

1 Sealing Head adopts copper material, good heat transfer effect,

2 Can apply to different sizes of battery

Vacuum degree

-95Kpa - 0

Sealing head

temperature

RT-250℃, adjustable

Temperature accuracy

±1.5℃

Sealing

 pressure

0-7Kg/cm2, adjustable

Sealing time

0-99s, adjustable

Sealing Blade

Hard type (without rubber, only for Al case sealing,

not suitable for sealing case with tab in between)

If you need heat sealer for Top&side sealing with rubber blade,please click the pic below

Sealing width

Customized according customer's request

Sealing head

length

Standard sealing length: 200mm

The sealing length can be customized according customer's request(100-500mm selectable)

Air source

0.5-0.7MPa (72.5-102psi)

Dimension

(L*W*H)

Sealing Unit with Chamber Closed: 470*430*480mm

Sealing Unit with Chamber opened: 470*430*559mm

Control Unit: 420*320*220mm

Weight

About 50kg

Note

For completing the full sealing procedure, you may need the following  combination:


a.Compact Heating Sealer(suitable for top&side sealing with tab)




b.Vacuum Sealing Machine(for preadling in glove box after injection of electrolyte)



c.Final Vacuum Sealing Machine(for vacuuming and second sealing with automatic puncture and degassing function)







 d.If you don't want to spend too much budget on the sealing part, we also can provide 3 in 1 sealing machine for you:




 Recommendation

 For the pouch cell assembly, we also recommend you the following items:



                              Pouch Cell Hot Vacuum Sealer Sealing Machine for Pre-Sealing after Electrolyte Injection             Pouch Cell Hot Vacuum Sealer Sealing Machine for Pre-Sealing after Electrolyte Injection

 Forming machine    Ultrasonic tab welder       Stacking machine    Die Cutter



Vacuum Sealing Machine


Pouch Cell Process: Tube Furnace/ Muffle Furnace→ Vacuum Mixing→ Electrode Coating→ Roll press→ Electrode Cutting→ Vacuum Drying→ Cases Forming→ Top&Side Sealing→ Electrolyte Filling→ Vacuum Sealing→ Battery Analyzer



For the pouch cell assembly, we also recommend you the following items:










PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
