ItemNo :
LITH-JY-S300TMOQ :
1Compliance:
Warranty:
2yearsDelivery Time:
5 days
Main parameter
|
Model |
200T |
250T |
300T |
350T |
|
Clamping force (T) |
200 |
250 |
300 |
350 |
|
Stroke (mm) |
300 |
300 |
300 |
300 |
|
Hot plate distance (mm) |
300-430 |
300-430 |
300-430 |
300-430 |
|
Work platform (mm) |
Upper: 510*510 Lower: 560*560 |
Upper: 600*600 Lower: 650*650 |
Upper: 600*600 Lower: 650*650 |
Upper: 700*700 Lower: 750*750 |
|
Main cylinder diameter (mm) |
360 |
400 |
450 |
475 |
|
Vacuum chamber travel (mm) |
200 |
200 |
200 |
300 |
|
Motor power (KW) |
9.5*2 |
9.5*2 |
9.5*2 |
11*2 |
|
Electrical power (KW) |
16*2 |
18*2 |
18*2 |
21*2 |
|
Vacuum pump (KW) |
Double heads(200m2/h) Single heads(100m2/h) |
~ |
~ |
~ |
|
Weight (KG) |
Double head 9000 |
11300 |
13300 |
16500 |
|
Type of mold opening |
Rise/Fall - Mold entry and exit - front ejection mold opening - (Middle mold opening - ejection device) |
|||
|
Dimensions (L*W*H, m) |
3.2*2.4*2.6 |
3.45*2.6*2.75 |
3.45*2.6*2.75 |
4.5*2.8*2.95 |
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to
production season and order quantity.
