Louis@lithmachine.comVacuum Planetary Centrifugal Mixer With Two 300 ML Containers for Lab
The planetary centrifugal vacuum mixer LITH-MSK-PCV-300-LD is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for best mixing results. The standard package includes two 300 mL containers and counter-weights. High-throughput adapters are also available for 6 samples (7 ml per sample) mixing per batch.
SPECIFICATIONS
|
Features |
· Compared with other brands of the planetary centrifugal mixer, LITH-MSK-PCV-300-LD has the following unique features: o Mixing under vacuum for deaeration o Dual containers for larger quantity o Minimized contamination (no metal mixing blade) o Low cost · Sample Materials o Nanopowders, ceramic powders o Grease o Slurry o Paste |
||||||||||||||||
|
Voltage Input |
Single Phase AC 208 - 240V, 50/60 Hz |
||||||||||||||||
|
Power |
· Maximum: 1500 W · Motor Power: 750 W |
||||||||||||||||
|
Mixing |
· Planetary Centrifugal Vacuum Mixing o The centrifugal force of rotation and revolution induces convection, homogenizing the materials o With the vacuum pressure, submicron air bubbles can be efficiently eliminated from the materials |
||||||||||||||||
|
Vacuum Capability |
· Pumping Rate: 165 L/min · Ultimate Vacuum: -95 kPa · Built-in vacuum pump with integrated control |
||||||||||||||||
|
Speed |
· Sample Platen Rotation (revolution motion):600 rpm - 2,000 rpm (adjustable) · Container Spin (rotation motion):360 rpm - 1,200 RPM (fixed at 0.6X of the revolution speed) · Customized ratio between revolution and rotation is available upon request at extra cost |
||||||||||||||||
|
Containers and Counter-Weights |
· Two standard containers and counter-weights are included o Two 300 mL containers with gas vent, made of high-density Polyethylene o Counter-weights (10, 20, 50 g) with adapter, made of high-density Polyethylene |
||||||||||||||||
|
Max. Mixing Volume and Weight |
· Attention: Sample overload might damage the motor and/or cause spilling. Follow both the volume and weight limit when loading. |
||||||||||||||||
|
Program
|
· Store up to 6 programs in memory, as shown in Fig.1 · 3 programmable segments, as shown in Fig.2. For example: o 800 rpm revolution speed (480 rpm rotation speed) for 60 sec;
o 1500 rpm revolution speed (900 rpm rotation speed) for 180 sec; o 1000 rpm revolution speed (600 rpm rotation speed) for 60 sec. · Maximum running time for each segment is 200 sec. Maximum total running time is 600 sec · The rotation direction could be either clockwise (mode A) or counter-clockwise (mode B) |
||||||||||||||||
|
Safety and Protection
|
· Safety warning and interlocks are integrated. The unit automatically stops when o The unit is overloaded with the sample o The sample is loaded in an unbalanced way o The top cover is opened |
||||||||||||||||
|
Dimension |
400 mm (W) x 590 mm (H) x 580 mm (D) |
||||||||||||||||
|
Weight |
90 kg (200 lbs) |
PACKAGE:
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to
production season and order quantity.
