TMAX-BE-ZK is a middle size vacuum oven with max working temperature 200°C and 27 - 512 Liter capacity. The oven adopts heat radiant wall system providing optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.
SPECIFICATIONS:
|
Model |
BE-ZK-27L |
BE-ZK-64L |
BE-ZK-125L |
BE-ZK-216L |
BE-ZK-512L |
|
The inner Chamber size(W*H*D mm) |
300*300 *300 |
400*400 *400 |
500*500 *500 |
600*600 *600 |
800*800 *800 |
|
Dimensions(W*H*D mm) |
600*470 *710 |
700*570 *810 |
800*670 *910 |
900*870 *1010 |
1100*1070 *1210 |
|
Net Weight |
90KG |
110KG |
130KG |
150KG |
200KG |
|
Input Power |
3.0KW |
4.0KW |
6.0KW |
8.0KW |
10.0KW |
|
Working Voltage |
AC 220V 50HZ |
AC 380V 50HZ |
|||
|
Working Temperature |
RT+10 ~ 200°C for the continuous use |
||||
|
Chamber and Door |
1. The chamber is
structured with stainless steel and welded to bracing pieces. |
||||
|
Interior material |
Stainless Steel 304 (6mm thick) |
||||
|
Exterior material |
Cold rolled steel plate (1.5mm thick) |
||||
|
Temperature Controller |
1. Single point
temperature setting |
||||
|
Fittings |
This oven comes with a KF-25 vacuum connector which allows you set up a quick connection to the vacuum pump. |
||||
|
Compliance |
CE Certified |
||||
|
Warranty |
One years limited warranty with lifetime technical support |
||||
|
Vacuum Pump (optional) |
Vacuum level displayed on gauges from -0.0116 ~ 0 Mpa (atmospheric pressure).Vacuum pump is not included. |
||||
|
Attention |
1. It's normal that the SS chamber wall will slightly deform and loose its shine during high-temperature operation. However, this would not affect any functionality. 2. Please do not place the sample on the chamber bottom directly. |
||||
