Small Slurry Vacuum Mixer with A 250ml Container


 MSK-SFM-7 is designed to produce coating slurry by mixing small batch of chemical and compound (500 ml Max) under vacuum to remove gas bubble and protect sample from oxidation. It has build-in pump which can vacuum the mixing container to 0.08Mpa(600 torr) and the stepless mixing speed variates from 0 to 320rpm. The vibration plate is located at the bottom to remove gas bubble before vacuum mixing and disperse the slurry after mixing to ensure better uniformity. It is excellent for preparing battery electrode paste and various ceramic materials in research lab.


Main Parameter:

Voltage Input

Single Phase 110VAC or 220VAC ( please choose from product  option bar ) 220V AC Power plug is not included.  Please click here to order the plug)

Power

150W

Rotary Speed

320 rpm

Mixing Container

One 250ml acrylic container (It can be customized)

Vacuum pump

Built in

Vacuum Level

-0.08~0.09 Mpa

Vibration Plate

Vibrating at 1000 Hz

Dimensions

13''L x 12''W x 21''H

Shipping Dimensions

16''L x 15''W x 24''H

Net Weight

70 lbs

Compliance

CE certified













Coin Cell Process:

Materilas → Powder Processing  →Powder Grinding Mill → Vacuum Mixing  → Electrode Coating → Roll Press  → Vacuum Drying  → Disc Cutter → Electrolyte Injection  → Crimping Machine  → Battery Analyzer





For the coin cell Assembly, we also recommend you the following items:







PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
