Lab Stainless Steel Vacuum Glove Box With Air-lock Chamber

Contact Now

Lab Stainless Steel Vacuum Glove Box With Air-lock Chamber

DESCRIPTION:

1.The whole box is made of stainless steel, which is reinforced and sprayed plastic on surface so that the box is anti-corrosion and easy to clean.

2.The inside of glove box can be seen clearly from the tempered glass visual window.

3.Installed electric bulb and socket can heat partially.

4. Thick latex gloves for operation have characteristics of sealing, reliable and durable.

5. The sealing device is designed new, reliable, and easy to start.

6. Water faucets are installed both inside and outside, which is easy for the gas or water to get in.

7. Two doors in transition cabinet solves the problem of pumping vacuum repeatedly for main box.

Parameters of Stainless Steel Vacuum Glove Box
No.	Model No.	Outline Dimension (mm)	Box Size (mm)	Transition Cabinet (mm)	Glove Port (mm)	Vacuum Degree
1	GBV-1	1030570530	600500500	Ф200*280	Ф145	0-0.1Mpa Keep vacuum for more than 12 hours
2	GBV-2	1295715675	800650650	Ф273*350	Ф145
3	GBV-3	17557761010	1200700950	Ф350*400	Ф196

SPECIFICATIONS:

Glove Box Chamber	1 Case Material: Made of 11 gauge (5mm thickness) 304 stainless steel sheet with sport frame and plastic painting, which provide heavy duty structure for vacuum 2 Dimensions: 800mm(L) x 650mm(W) x 650mm(H) 3 Max. Positive Pressure: 810 Torr (1.1 atm) 4 Note: Gloves cannot work if pressure is higher than 810 Torr 5 Max. Vacuum Level: 0.5 Torr 6 Note: Stainless Steel case may deform at higher vacuum level
Air-lock Chamber	Dimensions: 273mm(ID) x 350mm(L) Max. Vacuum Level: 0.05 Torr
Vacuum gauge and valves	1 Two vacuum flanges are included for glove box to achieve vacuum to remove moisture and oxygen without expensive inert gas purging 2 Do not operate under vacuum status. Vacuum process is used for purging the glove box chamber before operation.
Leakage Rate in Glove Box Chamber	< 6 Torr/hour
Gloves	One pair of Latex Gloves are included for immediate use Glove hole diameter : 139mm (2 pcs)
Shipping Dimensions	50" x 40" x 37"
Shipping Weight	240 kg (520 lbs)
